Ref No. |
Part Number |
Part Name |
QTY |
Price |
|---|---|---|---|---|
1.1 |
24131-33G80-000 |
SHAFT,DRIVE (NT:17) |
1 |
|
1.2 |
24131-33G90-000 |
SHAFT,DRIVE (NT:17) |
1 |
₱ 1,843 |
2 |
24150-39J40-000 |
SHAFT,IDLE (NT:13/42) |
1 |
₱ 4,242 |
3 |
09181-12167-000 |
SHIM (12X20X1) |
1 |
₱ 44 |
4.1 |
09262-20171-000 |
BEARING (20X47X14) |
1 |
₱ 385 |
4.2 |
09262-20158-000 |
BEARING (20X47X14) |
1 |
|
4.3 |
09262-20151-000 |
BEARING (20X47X14) |
1 |
|
5 |
09283-20069-000 |
SEAL,OIL (19X28X5) |
1 |
₱ 110 |
6 |
08110-6202A-000 |
BEARING (15X35X11) |
1 |
₱ 281 |
7 |
09262-12034-000 |
BEARING (12X32X10) |
1 |
₱ 293 |
8 |
09262-12035-000 |
BEARING (12X28X8) |
1 |
₱ 291 |
9 |
24141-08K10-000 |
SHAFT,REAR AXLE |
1 |
₱ 1,314 |
10.1 |
24371-39J10-000 |
GEAR,FINAL DRIVEN (NT:45) |
1 |
₱ 1,894 |
10.2 |
24371-39J20-000 |
GEAR,FINAL DRIVEN (NT:45) |
1 |
|
11 |
08331-31249-000 |
CIRCLIP |
1 |
₱ 28 |
12 |
24142-08K10-000 |
WASHER,FINAL DRIVEN GEAR |
1 |
₱ 200 |
13 |
24142-08K10-000 |
SHIM (T:0.60) |
1 |
₱ 200 |
14 |
09283-29007-000 |
SEAL,OIL |
1 |
₱ 88 |
15 |
09283-29007-000 |
BEARING |
1 |
₱ 88 |
16 |
09262-22041-000 |
BEARING (22X50X14) |
1 |
₱ 1,540 |
17 |
24751-09J00-000 |
RETAINER,DRIVE SHAFT BEARING |
1 |
₱ 109 |
18 |
02122-0616A-000 |
SCREW |
2 |
–
