Ref No. |
Part Number |
Part Name |
QTY |
Price |
|---|---|---|---|---|
1 |
24121-25G20-000 |
SHAFT,COUNTER (NT:12) |
1 |
|
2 |
24125-25G00-000 |
NOZZLE |
2 |
₱ 43 |
3 |
24221-25G10-000 |
GEAR,2ND DRIVE (NT:14) |
1 |
₱ 694 |
4 |
24231-25G10-000 |
GEAR,3RD & 4TH DRIVE (NT:19/21) |
1 |
₱ 863 |
5 |
09380-20009-000 |
CIRCLIP |
1 |
₱ 44 |
6 |
24251-25G10-000 |
GEAR,5TH DRIVE (NT:23) |
1 |
₱ 901 |
7 |
24261-25G21-000 |
GEAR,6TH DRIVE (NT:25) |
1 |
₱ 574 |
8 |
09262-20159-000 |
BEARING (20X47X14) |
1 |
₱ 260 |
9 |
24741-12B00-000 |
RETAINER,CNTR SHAFT BRG |
1 |
|
10 |
02112-0612A-000 |
SCREW |
2 |
|
11 |
09262-15L06-000 |
BEARING,COUNTER SHAFT,L (15X32X9) |
1 |
₱ 328 |
12 |
24131-25G20-000 |
SHAFT,DRIVE |
1 |
|
13 |
24311-25G10-000 |
GEAR,1ST DRIVEN (NT:33) |
1 |
₱ 641 |
14 |
08211-15251-000 |
WASHER |
1 |
₱ 67 |
15 |
24321-25G20-000 |
GEAR,2ND DRIVEN (NT:25) |
1 |
₱ 1,009 |
16 |
24331-25G10-000 |
GEAR,3RD DRIVEN (NT:26) |
1 |
₱ 625 |
17 |
24341-25G10-000 |
GEAR,4TH DRIVEN (NT:23) |
1 |
₱ 608 |
18 |
24351-25G10-000 |
GEAR,5TH DRIVEN (NT:21) |
1 |
₱ 796 |
19 |
24361-25G10-000 |
GEAR,6TH DRIVEN (NT:20) |
1 |
₱ 717 |
20 |
09380-20009-000 |
CIRCLIP |
1 |
₱ 44 |
21 |
09167-20011-000 |
LOCK WASHER (20.5X25X0.5) |
1 |
₱ 69 |
22 |
09181-20167-000 |
SHIM (20X28X1.0) |
1 |
|
23.1 |
09263-15023-000 |
BEARING (15X19X7.8) |
1 |
₱ 536 |
23.2 |
09263-15049-000 |
BEARING,1ST DRIVEN GEAR (15X42X13) |
1 |
|
24 |
24359-05200-000 |
WASHER,OIL SEALING (20X40X1) |
1 |
₱ 65 |
25 |
08113-62020-000 |
BEARING |
1 |
₱ 257 |
26 |
09283-27023-000 |
SEAL,DRIVE SHAFT OIL (27X40X6) |
1 |
₱ 170 |
27 |
09262-20159-000 |
BEARING (20X47X14) |
1 |
₱ 260 |
28 |
24741-05200-000 |
RETAINER,DRIVE SHAFT BEARING |
2 |
₱ 237 |
29 |
02122-0612A-000 |
SCREW |
2 |
₱ 49 |
30 |
24751-05210-000 |
RETAINER,DRIVE SHAFT OIL SEAL |
1 |
₱ 68 |
31 |
01500-0610A-000 |
BOLT |
2 |
|
32.1 |
27511-25G20-000 |
SPROCKET,ENGINE (NT:14) |
1 |
₱ 296 |
32.2 |
27511-25G20-000 |
SPROCKET,ENGINE |
1 |
₱ 296 |
33 |
27512-25G00-000 |
PLATE,ENGINE SPROCKET |
1 |
₱ 68 |
34 |
27531-25G00-000 |
SPACER,ENGINE SPROCKET |
1 |
₱ 151 |
35.1 |
27600-16H40-120 |
CHAIN ASSY,DRIVE (120L) |
1 |
₱ 1,375 |
35.2 |
27600-01G30-120 |
CHAIN ASSY,DRIVE (RK 428HSB,120L) |
1 |
₱ 1,211 |
36.1 |
27620-16H40-000 |
.JOINT SET, CHAIN |
1 |
|
36.2 |
27620-01G30-000 |
.JOINT,CHAIN |
1 |
₱ 155 |
37 |
07130-0610A-000 |
BOLT |
2 |
₱ 44 |
38 |
09280-19005-000 |
O RING (D:2.4,ID:19) |
1 |
₱ 28 |
–
