Ref No. |
Part Number |
Part Name |
QTY |
Price |
|---|---|---|---|---|
1 |
25211-24F20-000 |
FORK, GEAR SHIFT NO.1 |
2 |
₱ 3,585 |
2 |
25231-24F20-000 |
FORK, GEAR SHIFT NO.3 |
1 |
₱ 3,617 |
3 |
25411-24F00-000 |
SHAFT, GEAR SHIFT NO.2 |
1 |
₱ 624 |
4 |
25411-38B01-000 |
SHAFT, GEAR SHIFT NO.1 |
1 |
₱ 638 |
5 |
25310-10L00-000 |
CAM,GEAR SHIFT |
1 |
₱ 6,993 |
6 |
04221-04089-000 |
PIN, CAM STOPPER PLATE |
1 |
₱ 38 |
7 |
09263-25018-000 |
BEARING (25X32X12) |
1 |
|
8 |
09262-25006-000 |
BEARING (25X47X8) |
1 |
₱ 841 |
9 |
24741-24F10-000 |
RETAINER, SHIFT CAM BEARING |
1 |
₱ 213 |
10 |
09126-06011-000 |
SCREW (6X12) |
2 |
₱ 87 |
11 |
25381-10L00-000 |
PLATE,GEAR SHIFT CAM |
1 |
₱ 1,745 |
12 |
25312-10L00-000 |
STOPPER,SHIFT CAM DRIVE PLATE |
1 |
₱ 4,441 |
13 |
25314-10L00-000 |
BOLT,GEAR SHIFT CAM PLATE |
1 |
₱ 130 |
14 |
25355-06J00-000 |
SPRING,GR SHT CAM STOPPER ARM |
1 |
₱ 177 |
15 |
08211B06141N000 |
WASHER |
1 |
₱ 39 |
16 |
25350-24F10-000 |
STOPPER,SHIFT CAM |
1 |
|
17 |
09111-06041-000 |
BOLT,6X14.3 |
1 |
₱ 75 |
18 |
25671-01011-000 |
STOPPER, GEAR SHIFT |
1 |
₱ 124 |
19 |
09263-14027-000 |
BEARING |
1 |
₱ 482 |
20 |
09181-14195-000 |
SHIM (14X24X1) |
2 |
₱ 104 |
21 |
08331-3114A-000 |
CIRCLIP |
2 |
|
22 |
25518-06L00-000 |
SPRING,GEAR SHIFT SHAFT RETURN |
1 |
₱ 155 |
23 |
25510-10L00-000 |
SHAFT,GEAR SHIFT |
1 |
₱ 2,373 |
24 |
25512-06G20-000 |
PLATE,GEAR SHIFT CAM DRIVE |
1 |
₱ 846 |
25 |
09440-17009-000 |
SPRING, GEAR SHIFT PLATE |
1 |
₱ 48 |
26 |
09283-14020-000 |
SEAL,OIL (14X22X7.3) |
1 |
|
27 |
25600-10L00-000 |
LEVER ASSY,GEAR SHIFT |
1 |
₱ 4,531 |
28 |
25526-47001-000 |
.COVER, DUST |
1 |
₱ 155 |
29 |
25652-20C00-000 |
.RUBBER, GEAR SHIFT PEDAL |
1 |
₱ 60 |
30 |
09160-10144-000 |
WASHER (10X30X2.5) |
1 |
₱ 126 |
31 |
25617-17K00-000 |
SHAFT,GEAR SHIFT LEVER |
1 |
₱ 678 |
32 |
25619-17K00-000 |
WASHER,GEAR SHIFT LEVER LH |
1 |
₱ 136 |
33 |
01547-0625A-000 |
STUD BOLT |
1 |
₱ 25 |
34 |
25520-10L00-000 |
ARM COMP,GEAR SHIFT LINK |
1 |
₱ 2,608 |
35 |
25526-47000-000 |
.COVER, DUST |
1 |
₱ 155 |
36 |
09140-06025-000 |
NUT |
1 |
₱ 16 |
37 |
25525-10L00-000 |
ROD,GEAR SHIFT LINK |
1 |
₱ 1,927 |
38 |
09140-06020-000 |
NUT |
2 |
₱ 52 |
39 |
25500-10810-000 |
SENSOR & ROD SET |
1 |
₱ 21,211 |
40 |
37732-10L00-000 |
PLATE,GEAR POSITION SNSR |
1 |
₱ 179 |
41 |
09280-26005-000 |
ORING D:2.4 ID:26.2 |
1 |
₱ 59 |
42 |
37730-10L00-000 |
SENSOR ASSY,GEAR POSITION |
1 |
₱ 5,591 |
43 |
37733-10L00-000 |
NUT,GEAR SHIFT SW |
2 |
₱ 1,349 |
44 |
36990-06L00-000 |
CLAMP,HANDLE SWITCH (L:145) |
1 |
₱ 240 |
–
