Ref No. |
Part Number |
Part Name |
QTY |
Price |
|---|---|---|---|---|
1 |
51103-10L00-000 |
DAMPER ASSY,R |
1 |
₱ 68,664 |
2 |
51110-10L00-000 |
.TUBE,INNER RH |
1 |
₱ 35,504 |
3 |
51351-10L00-000 |
.CAP |
1 |
₱ 7,271 |
4 |
62278-14100-000 |
..O RING |
1 |
₱ 110 |
5 |
51131-10L00-000 |
.TUBE,OUTER |
1 |
₱ 27,762 |
6 |
51158-40F30-000 |
.GUIDE, SPRING |
1 |
₱ 221 |
7 |
51176-40F30-000 |
.SPACER, SPRING |
1 |
₱ 564 |
8 |
51171-10L00-000 |
.SPRING |
1 |
₱ 3,155 |
9 |
51352-13A60-000 |
.NUT |
1 |
₱ 64 |
10 |
51146-10L00-000 |
.CYLINDER |
1 |
₱ 19,453 |
11 |
51112-31J00-000 |
.PISTON |
1 |
₱ 259 |
12 |
51152-31J00-000 |
.SLIDEMETAL |
1 |
₱ 242 |
13 |
51158-14200-000 |
.WASHER |
1 |
₱ 130 |
14 |
51153-41G00-000 |
.OIL SEAL |
1 |
₱ 717 |
15 |
51156-14200-000 |
.RING, OIL SEAL STOPPER |
1 |
₱ 132 |
16 |
51173-41G00-000 |
SEAL, OIL |
1 |
₱ 754 |
17 |
51148-41310-000 |
GASKET,FORK CYLINDER |
1 |
₱ 58 |
18 |
51147-24F50-000 |
.BOLT |
1 |
₱ 187 |
19 |
51104-10L00-000 |
DAMPER ASSY,L |
1 |
₱ 68,664 |
20 |
51120-10L00-000 |
.TUBE,INNER LH |
1 |
₱ 35,504 |
21 |
51351-10L00-000 |
.CAP |
1 |
₱ 7,271 |
22 |
62278-14100-000 |
..O RING |
1 |
₱ 110 |
23 |
51131-10L00-000 |
.TUBE,OUTER |
1 |
₱ 27,762 |
24 |
51158-40F30-000 |
.GUIDE, SPRING |
1 |
₱ 221 |
25 |
51176-40F30-000 |
.SPACER, SPRING |
1 |
₱ 564 |
26 |
51171-10L00-000 |
.SPRING |
1 |
₱ 3,155 |
27 |
51352-13A60-000 |
.NUT |
1 |
₱ 64 |
28 |
51146-10L00-000 |
.CYLINDER |
1 |
₱ 19,453 |
29 |
51112-31J00-000 |
.PISTON |
1 |
₱ 259 |
30 |
51152-31J00-000 |
.SLIDEMETAL |
1 |
₱ 242 |
31 |
51158-14200-000 |
.WASHER |
1 |
₱ 130 |
32 |
51153-41G00-000 |
.OIL SEAL |
1 |
₱ 717 |
33 |
51156-14200-000 |
.RING, OIL SEAL STOPPER |
1 |
₱ 132 |
34 |
51173-41G00-000 |
SEAL, OIL |
1 |
₱ 754 |
35 |
51148-41310-000 |
GASKET,FORK CYLINDER |
1 |
₱ 58 |
–
